12V 85Ah LiFePo4 Deep Cycle Battery


    BSLBATT's energy storage batteries are not only easy to install and use, they also help you to save on electricity costs. High energy density and a wide temperature range enhance the user experience.
Product List/Catalog Download

BSLBATT® batteries are based on Lithium iron battery technology (LiFePO4). Compared to lead-acid alternatives, this 12V85Ah battery is the perfect combination of size and capacity to fit many applications including, RV, marine, solar energy systems and more.it's a lightweight alternative to lead-acid and one of our most popular lithium batteries.

LiFePO4 batteries can be discharged up to 100% without risk of damage. Make sure you charge your battery immediately after discharge. We recommend discharging be limited to 80-90% depth of discharge (DOD) to avoid the BMS disconnecting the battery.



  • Whether you are ready to order or just want a price quote we will do our best to assist you. Please fill in the form below with your contact info, or send your inquiry to inquiry@bsl-battery.com, we will get back to you as soon as possible.
  • Lift Trucks
  • Solar
  • UPS
  • Telecom
  • Industrial
  • Remote Power
  • Military
  • RV
  • Utility batteries
  • Marine
  • Mining

■ SPECIFICATIONS

Items Parameter
Battery Type LiFePO4
Nominal Voltage 12V
Nominal Capacity 85Ah
Energy 1020 WH
Dimensions (L x W x H) 262*167*212MM
Weight 12.8KG
Case Material ABS/Iron case
Certifications CE/ISO/UN38.3/MSDS
Efficiency 99%
Self Discharge <1% per Month
Series & Parallel Application max. 4 series or 4 parallel connected application
Peak Discharge Current 160 A
Continus Discharge Current 80 A
Operation Temperature Range -20~60℃
Voltage at end of Discharge 12.8 V
Working Voltage 10-14.4V
Discharge Temperature -4 to 140 ºF (-20 to 60 ºC)
Charge Temperature 32 to 113 ºF (0 to 45 ºC)
Storage Temperature 23 to 95 ºF (-5 to 35 ºC)
Cycle Life > 2000 cycles
Self-Discharge Rate Residual capacity: ≤3%/month; ≤15%/years
Reversible capacity: ≤1.5%/month; ≤8%/years
Storage Temperature & Humidity Range Less than 1 month: -20℃~35℃, 45%RH~75%RH
Less than 3 months: -10℃~35℃, 45%RH~75%RH
Recommended storage environment: 15℃~35℃,45%RH~75%RH



■ Product List

Models Voltage(V) Nominal Capacity(AH) Max.charge current(A) Weight(kg)+/-5% Dimension(+/-3mm) Cycle life DOD 100%
L(mm) W(mm) H(mm)
B-LFP12-40 12 40 20 6 195 130 168 >2000
B-LFP12-50 12 50 30 7 229 138 213 >2000
B-LFP12-80 12 80 30 12.8 262 167 212 >2000
B-LFP12-100 12 100 50 14 323 173 218 >2000
B-LFP12-120 12 120 60 16 323 173 218 >2000
B-LFP12-150 12 150 75 24 485 172 240 >2000
B-LFP12-170 12 170 85 26 485 172 240 >2000
B-LFP12-200 12 200 100 30 520 269 205 >2000
B-LFP12-240 12 240 120 34.2 520 269 208 >2000
B-LFP24-50 24 50 25 14.8 520 380 290 >2000
B-LFP24-100 24 100 50 28 520 450 350 >2000
B-LFP24-150 24 150 50 42 520 450 400 >2000
B-LFP24-200 24 200 50 56 520 380 290 >2000
B-LFP24-250 24 250 50 70 600 450 350 >2000
Because the model is numerous, only displays the part, may contact us to understand more!



■ Battery Management System:

The lithium batteries are supplied with Battery Management System that can monitor and optimize each single cell during charge and discharge, to protect the battery pack from damage agains over-charge, over-discharge, short circuit. The BMS helps to ensure safe and accurate running.

Items Content Specification
Over Charge Over-charge protection for each cell 3.8±0.03V
Over-charge release for each cell 3.60±0.05V
Over-charge release method Under the release voltage
Over Discharge Over-discharge protection for each cell 2.3±0.05V
Over-discharge release for each cell 2.8±0.05V
Over-discharge release method Charge to recovery
Over Current Over discharge current protection 300A~500A
Protection delay time 50ms~200ms
Over current release method Delay about 8S after recovery
Short Circuit Do not short-circuit the electrodes Designed for 600A/500us
Battery Temperature Charge over temperature Protection @ 65±5℃
Release @ 50±5℃
Discharge over temperature Protection @ 65±5℃
Release @ 50±5℃
MOSFET over temperature Protection @ 103±10℃
Release @ 75±10℃
