Energy Storage
BPDG Series-Industry Energy Storage Battery
-
The BPDG Series integrate patent nano gel electrolyte with up-to-date AGM structure. The range offers over 12 years design life with very high deep cycling capabilities. This range is highly suited to telecom outdoor application, renewable energy system a
Features：
★ Superior deep cycle design with high percentage tin
★ Thick plates and high power density
★ Active paste material, and a slightly stronger acid
★ Adopts silicon dioxide electrolyte in gelled state to avoid acid leakage
★ Nano gel electrolyte eliminate the acid stratification and prolong cycle life
★ 12-15 years design life at floating condition
★ Wide operating temperature range from 20°C/68℉
★ Can be used at vertical or horizontal orientation
★ Low self-discharge rate and long shelf life
★ Excellent deep discharge recovery capability
Application
● Telecommunications system
● Hybrid solar power system
● Uninterrupted Power Supply (UPS)
● Communications and electric equipment
● Emergency lighting equipment
● Fire alarm and security systems
● Robots, control equipment, and other factory automation equipment
● Emergency power supply (EPS)
● Various power toys and hobby equipment
● Renewable energy system
| Battery Model | Rated voltage |
20Hr Capacity | Length | External Dimension | Weight | Terminal | ||
| Width | Height | Total Height | Approx | |||||
| （V） | （AH） | MM | MM | MM | MM | Kgs | ||
| BPDG6-200 | 6 | 200/20HR | 306 | 168 | 220 | 222 | 30.5 | T5 |
| BPDG6-210 | 6 | 210/20HR | 260 | 180 | 247 | 249 | 30 | T5 |
| BPDG6-220 | 6 | 220/20HR | 306 | 168 | 220 | 222 | 32.0 | T5 |
| BPDG6-225 | 6 | 225/20HR | 243 | 187 | 275 | 275 | 31.5 | T6 |
| BPDG6-310 | 6 | 310/20HR | 295 | 178 | 346 | 366 | 46.0 | T7 |
| BPDG6-330 | 6 | 330/20HR | 295 | 178 | 354 | 360 | 46.6 | T6 |
| BPDG6-380 | 6 | 380/20HR | 295 | 178 | 404 | 410 | 55.5 | T5/T6 |
| BPDG6-420 | 6 | 420/20HR | 295 | 178 | 404 | 410 | 56.8 | T5/T6 |
| Battery Model | Rated voltage |
20Hr Capacity | Length | External Dimension | Weight | Terminal | ||
| Width | Height | Total Height | Approx | |||||
| （V） | （AH） | MM | MM | MM | MM | Kgs | ||
| BPDG12-24 | 12 | 25/20HR | 166 | 175 | 126 | 126 | 8.3 | T1 |
| BPDG12-26 | 12 | 25/20HR | 165 | 180 | 174 | 179 | 8.4 | T1 |
| BPDG12-35 | 12 | 35/20HR | 196 | 126 | 155 | 167 | 10.5 | T3 |
| BPDG12-40 | 12 | 40/20HR | 198 | 130 | 174 | 174 | 14.5 | T2 |
| BPDG12-55 | 12 | 55/20HR | 229 | 166 | 208 | 212 | 16.0 | T3 |
| BPDG12-70 | 12 | 70/20HR | 350 | 138 | 178 | 178 | 23.5 | T3 |
| BPDG12-75 | 12 | 75/20HR | 260 | 167 | 208 | 227 | 25.0 | T3 |
| BPDG12-85 | 12 | 85/20HR | 260 | 169 | 208 | 227 | 26.1 | T3 |
| BPDG12-90 | 12 | 90/20HR | 307 | 169 | 211 | 216 | 28.5 | T3 |
| BPDG12-100 | 12 | 100/20HR | 307 | 169 | 211 | 216 | 30.5 | T4 |
| BPDG12-110 | 12 | 110/20HR | 331 | 174 | 214 | 220 | 33.5 | T5 |
| BPDG12-120 | 12 | 120/20HR | 407 | 173 | 210 | 233 | 39.5 | T5 |
| BPDG12-135 | 12 | 135/20HR | 344 | 172 | 280 | 285 | 41.5 | T4 |
| BPDG12-150 | 12 | 150/20HR | 484 | 171 | 241 | 241 | 46.0 | T4 |
| BPDG12-180 | 12 | 180/20HR | 532 | 206 | 216 | 222 | 56.0 | T5 |
| BPDG12-200 | 12 | 200/20HR | 532 | 206 | 216 | 222 | 58.8 | T5 |
| BPDG12-220 | 12 | 220/20HR | 522 | 240 | 219 | 225 | 64.0 | T5 |
| BPDG12-240 | 12 | 240/20HR | 520 | 268 | 220 | 226 | 71.0 | T5 |
